Jacobsen Tri King Parts & Maintenance Manual

39
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1002264.7 1 Angle Bracket
> 2 441602 2 Carriage Bolt, 5/16-18 x 3/4”
3 4196485 1 Steering Valve
1 • Seal Kit
4 444718 4 Locknut, 5/16-18 Center
5 362469 1 U-Bolt Clamp
6 450171 4 Screw, M6-1 x 20 mm Hex Head
7 450410 4 Lockwasher, M6
8 444310 4 Nut, #10-24 Hex
9 403914 4 Screw, #10-24 x 3/4” Truss Head
10 446116 4 Lockwasher, #10
11 403770 2 Screw, 5/16-18 x 3/4 Hex Flange
12 3003540.7 1 Mounting Bracket
13 3002098 2 Latch
14 404016 4 Screw, 1/4-20 x 5/8” Truss Head
15 3003468 2 Plastic Plate
16 2810209 1 Console Cover
17 452004 8 Flat Washer, 1/4
18 446130 8 Lockwasher, 1/4 Hvy
19 443102 8 Nut, 1/4-20 Hex
20 3003541 2 Latch Bracket
21 441664 4 Screw, 1/4-20 x 5/8” Round Head
22 2811364 1 Steering Wheel
23 2811365 1 • Steering Wheel Cap
24 447224 1 Lockwasher, 5/8 Internal Tooth
25 2811547 5 Washer
26 4211400 4 Spacer
27 64205-054 4 Screw, M8-1.25 x 130 mm Hex Head
28 4210420 1 Shaft, Steering
4201840 1 • Seal Kit, Steering Shaft
29 443828 1 • Nut, 5/8-18 Hex Jam
