Jacobsen Tri King Parts & Maintenance Manual

59
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4189580 1 Diesel Engine (Kubota D7222)
2 5002644 1 • Oil Filter Cartridge
3 4127309.7 1 Engine Front Bracket
4 2811637.7 1 Engine Rear Bracket
5 452008 8 Flat Washer, 3/8
6 363485 8 Lockwasher, M10
7 362263 8 Bolt M10-1.25 x 25mm
8 2810499.7 1 Engine Pulley
9 446136 8 Lockwasher, 5/16 Hvy
10 2810545 5 Screw, SKT Button Cap
11 2809727 1 Clutch
12 4130754.7 1 Pump Mount Bracket
13 4174020 1 Hydraulic Pump, Reel
See 31.1 for Service Parts
14 400226 4 Screw, 5/16-24 x 1” Hex Head
15 3001950 1 V-Belt
16 364501 1 Temperature Sender Reference U5
17 446128 1 Lockwasher, 1/4
18 361001 1 Nut, M6-1
19 4141024 1 Fan, Engine Cooling
20 4125492 1 Spacer, Fan
21 363448 4 Screw, M6-1 x 35 mm Hex Head
22 446130 4 Lockwasher, 1/4 Heavy
23 452004 4 Flat Washer, 1/4
24 4210160 1 Spacer, Pump Mount
