67
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4129590 1 Hydraulic Pump
2 340070 1 Adapter, 90°
3 340061 1 Adapter, 90°
4 339989 2 Adapter, Straight
5 339983 1 Adapter, Straight
6 307374 1 Washer
7 454001 2 Spring Washer
8 463005 1 Key, 1/8 x 5/8” Woodruff
9 1004900 1 Traction Arm
10 453017 1 Flat Washer, 1/2
11 444758 1 Locknut, 1/2-13 Center
12 463113 1 Key, 3/16 x 3/4” Morton
13 4129589 1 Universal Joint
554663 1 • Cross and Bearing Kit
14 4129588 1 Fan
15 412020 2 Screw, 5/16-18 x 1” Set
16 400272 2 Screw, 3/8-16 x 2-1/4” Hex Head
17 400274 1 Screw, 3/8-16 x 2-1/2” Hex Head
18 446142 4 Lockwasher, 3/8 Hvy
19 400276 1 Screw, 3/8-16 x 3” Hex Head
20 2810439 1 Bracket
21 1001148 1 Filter Assembly
549597 1 • Filter Cartridge
22 340068 2 Adapter, 90°
23 340120 1 Adapter, Tee
24 400108 2 Screw, 1/4-20 x 3/4” Hex Head
25 446130 2 Lockwasher, 1/4 Hvy
26 443110 2 Nut, 3/8-16 Hex
27 452004 2 Flat Washer, 1/4
To Next Page
