TECHNICAL SPECIFICATIONS
ARBUS 400Arbus 400 technical specifications
Table 1: Arbus 400 technical specifications
Model ARBUS 400
Weight
Empty machine weight 639 lb
Dimensions
Total lenght 68.90 in
Width 43.31 in
Height 61.81 in
Main reservoir
Material Polyethylene
Capacity 105 gallons
Clean water reservoir
Material Polyethylene
Capacity 3 gallons
Level gauge Level indicator with graduated scale
Agitation Through hydraulic return
Pump
Model JP-75
Pumping capacity 19.80 gpm
Maximum working pressure 35 kgf/cm2 / 500 psi
Power needed 5.3 HP at 540 rpm on the TDP
Pressure gauge
Model with extended scale
Control
Model VAR
Chemicals lter
Model FVS-101
Mesh 30
Noozle holder
Model with valve
Quantity 22
Noozle model J4-2
Maximum pressure 14 kgf/cm2 / 200 psi
Recommended working velocity 1.5 to 4 mph
Optional
Filler unit EJ-250
Herbicide application kit PH kit
