Jacto ARBUS 400 - PTO Shaft (Conventional)

5-89
5
MAINTENANCE
ARBUS 400 PTO shaft (conventional)
Use and maintenance
• Couple the PTO shaft to the power take-o.
• Adjust the length by cutting the bars and
protection in matching proportion.
Use, maintenance, disassembly and assembly of PTO shaft with protection
• Lubricate the male and female bars.
• Couple the drive shaft and install the sa-
fety chain.
• In too tight maneuvers, switch o the
power take-o.
ATTENTION!
Only operate with the PTO shaft provided with safety guard. Every kind of mainte-
nance to the PTO shaft shall be performed when wearing PPEs such as: protection
gloves, boots, goggles, etc. These operations shall be carried out with the machine
standing and the tractor engine shut down.
OBSERVATION:
File off and clean all burrs.
OBSERVATION:
Install the chain mak ing allowan-
ce for the angular movements.
ATTENTION!
Only operate with the PTO shaft
provided with safety protection.
