Jacto ARBUS 400 User Manual

5-90
5
MAINTENANCE
ARBUS 400PTO shaft (conventional)
Disassembly:
1. Remove locking screw.
2. Turn the cone up to the indicated posi-
tion.
3. Loosen the safety protection.
4. Remove the slide ring.
Assembly:
1. Clean and lubricate the PTO shaft bars.
2. Install the sliding ring into the recess
with the grooves facing the bar.
3. Fit the safety protection.
4. Turn the cone until the indicated posi-
tion.Encaixe a proteção de segurança.
5. Fasten the locking screw.
