Jacto ARBUS 400 - Spray Gun (Optional)

4-49
4
OPERATION AND ADJUSTMENTS
ARBUS 400
• This is a component for spot spraying
on big plants requiring high application
rate.
• It is possible to have flow rate ranging
from 5 to 45 liters per minute by shifting
the spray discs.
Spray discs - series D
• Made in stainless steel, these discs are
designed to be used on the Jacto spray
gun for spot spraying on fruit trees due
to its large application range, as well as
for cleaning sheds, warehouses and agri-
cultural equipment.
• The spray discs are available with ow rate
ranging from 5 to 45 liters per minute.
Spray gun (Optional)
Table 15: Spray discs
Nozzles
P/N
Spray discs
Pressure (lbf/pol
2
)
100 150 200 300 400
Gun ow rate (L/min)
202275 D-5 5,20 6,00 7,00 8,00 9,50
202267 D-6 6,85 8,50 10,00 12,00 13,50
202811 D-7 9,35 10,90 12,50 14,75 17,00
202259 D-8 12,85 15,00 17,00 20,00 23,65
622829 D-9 14,20 17,64 20,72 25,40 29,40
114686 D-10 18,50 22,00 25,50 30,00 35,68
622837 D-11 21,00 24,75 29,35 37,00 45,00
