JADEVER SCALE CO., LTD - www.dongminhphat.com
12 JCL Service Manual - www.cantudong,com
1) Use key M-/HI or PRINT/LO to choose the capacity.
Use key MR or TARE to move the decimal point.
Use key SMPL to choose the unit.
2) Or use key G/N/SET to set the capacity freely, use key MR or TARE to shift leftwards
or rightwards, use M-/HI or PRINT/LO to set the value or move the decimal point, and
use SMPL to choose the unit.
After setting the capacity, use key M+/SAVE to save the setting and advance to division
setting.
Division Setting:
After enter the division setting parameter, the screen will show Division such as 0.2G.
1) Use key M-/HI or PRINT/LO to choose the division.
Use key MR or TARE to move the decimal point.
2) Or use key G/N/SET to set the capacity freely, use key MR or TARE to shift leftwards or
rightwards, use M-/HI or PRINT/LO to set the value or move the decimal point.
After setting, use key M+/SAVE to save the setting and advance to calibration, or use key
ZERO/ESC to cancel the settings and return to weighing mode.
4-2 Single point calibration
1）Press and hold key TARE while powering on the scale. The screen displays “CAL” and unit
chosen, then release the keys.
2）Press key TARE to enter the zero point calibration mode, with “ 0.00 ” appears then
flashes. （ Please put no load on the weighing pan at the moment.）
3) Wait till “ 1.00kg (the value of 1/3 full capacity) " appears or set the calibration value by
pressing G/N/SET , and use key MR or TARE to shift leftwards or rightwards, use M-/HI
or PRINT/LO to set the value and use M+/SAVE to save value. Put the corresponding
weights on the weighing pan and press key TARE, the calibration procedure starts, press
M+/SAVE and the calibration procedure will be completed with a“ ” displayed on the
screen and return to normal weighing mode.
