Jadever JCL Service Manual

JADEVER SCALE CO., LTD - www.dongminhphat.com
2 JCL Service Manual - www.cantudong,com
10
Xm Shipping protection screw
1
JCL-10
31-0404-0000xm
11
Xm Leveling foot
4
JCL-11
01-0100-0030
12
Xm RS232 board
1
JCL-12
80-0900-2200xm
13-1
Xm TRUE-TEC load cell-10k
1
JCL-13
51-0701-0010
13-2
Xm TRUE-TEC load cell-20k
1
JCL-13
51-0701-0020
13-3
Xm TRUE-TEC load cell-35k
1
JCL-13
51-0701-0030
14
Xm Rechargeable battery
1
JCL-14
61-0201-0098xm
15
Xm Battery cover
1
JCL-15
02-0000-6030
16
Xm Rear display
1
JCL-16
80-0126-0010
17
Xm Upper support
1
JCL-17
10-0425-0000
18
Xm Upper cover
1
JCL-18
02-0000-6000
19
Xm Rear panel
1
JCL-19
20-1925-0010
20
Xm Plastic weighing pan
1
JCL-20
02-0000-6040
21
Xm Stainless Steel weighing pan
1
JCL-21
12-0000-1200
2. Electronic Structure
2 – 1 System block

Jadever JCL Specifications

General

Brand	Jadever
Model	JCL
Category	Scales
Language	English
