JAKA Zu
®
7 - V1.1 38
5. Connect the power plug of the electrical cabinet.
9.3 Turn on/off the Electrical cabinet
After plugged in, turn the emergency stop button clockwise to reset it. Press the power on button to turn on
the electrical cabinet, and then start working.
9.4 Turn on/off the Robot
If the electrical cabinet is powered on, and none of the emergency stop buttons is activated, the robot then
can be turned on. The way to turn it on is to touch the “Power on” button on the initialized page of the APP
(refer to fig 10-1), and then click the “Turn on robot” button. After turning on the robot, all brakes are unlocked.
The robot will make some noise and move a little. The robot can be turned off by touching the “Turn off robot”
button on the initialized page of the APP, or by turning off the electrical cabinet.
