JAKA Zu 7 - Function Buttons Area; Programing Demonstration

JAKA Zu
®
7 - V1.1 55
separate file in the disks or be hidden to avoid accidental modifications.
10.5.3 Function buttons area
Icon
Industry terminology
Function
Start execution button
Click to start program execution. It will switch to “Stop
execution button” during operation.
New program
Click to create a new program.
Save program
Save the completed program file.
Open program
Open the saved program file.
Overall speed
Change the command speed of current program executed.
Fig10-34
10.5.4 Programing demonstration
There is a simple program case to demonstrate the application of specific program commands.
(1)Open the “Control” select tab. Choose the default command of repeat 10 times, and drag it
and align the bottom of
Fig 10-35
