JAKA Zu
®
7 - V1.1 43
Fig 10-8
The current position of the robot is displayed in real time in 3D perspective. Fingers can slide left and
right across the model area to check the joint position of the robot more easily. (As shown in Fig 10-8)
10.3 Log Information Page
Fig 10-9
This page is divided into two areas: robot list and log information.
10.3.1 Robot list area
Fig 10-10
 This area shows all the running robots in the current LAN，
