ENGLISH
Jandy
®
Pro Series, JXi
™
Gas-Fired Pool & Spa Heater
|
Installation & Operation Manual
11.4 Heat System Spare Parts List and Exploded Parts Diagrams
11.4.1 Combustion Chamber Assembly Spare Parts List
Key No* Description model 200 model 260 model 330 model 400
1 Exhaust Elbow Assembly Kit R0590200 R0590200 R0590200 R0590200
2 Band Clamp Kit R0590400 R0590400 R0590400 R0590400
3 Refractory Kit, Internal R0590500 R0590500 R0590500 R0590500
4 Combustion Chamber Kit R0590600 R0590600 R0590600 R0590600
5 Combustion Chamber Shelf
(set of 3: Models 200, 260, 330)
R0590700 R0590700 R0590700 R0590700
6 Combustion Chamber Lid Kit R0590800 R0590800 R0590800 R0590800
7 Gasket Kit R0590900 R0590900 R0590900 R0590900
8 Sight Glass Kit R0305400 R0305400 R0305400 R0305400
9 Ignitor Kit R0457502 R0457502 R0457502 R0457502
10 Insulation Kit, External R0591000 R0591000 R0591000 R0591000
11 Isolator Kit (Thermal) R0593200 R0593200 R0593200 R0593200
12 Heat Exchange Assembly R0589402 R0589403 R0589404 R0589405
* Key No refers to Section 11.4.2 Combustion Chamber Assembly Exploded Parts Diagram
