Page 12
Jandy
Heat Pump Models EE-Ti Installation and Maintenance Manual
Figure 6. Two (2) Heat Pump Plumbing Layout
Figure 7. Four (4) Heat Pump Plumbing Layout
Manual Bypass Valve
2” PVC
3” PVC
Optional
Isolation Valves
From Filter
To Pool
Manual Bypass Valve
Optional
Isolation Valves
From Filter
To Pool
2” PVC
3” PVC
