Page 21
Jandy
Heat Pump Models EE-Ti Installation and Maintenance Manual
A Maintain Temp Relay is required (provided) and
the feature must be enabled.
When the temperature of the water rises above the
desired temperature setting, the control will then turn on
the unit and the associated right green LED will light.
To operate in pool mode with the Maintain Chill
feature, press
POOL, then press MENU, then press
the
Down button until MAINTAIN POOL CHILL is
displayed, press the MENU button. The associated
left green LED indicator will light and the unit will
display
SET:XXX°. Change the temperature set point
by pressing the
Up or Down button until the desired set
point is displayed. After 5 seconds of inactivity, the new
set point is stored in memory.
5.3.3 Spa Mode - (Optional Maintain Chill)
If connected, the Maintain Chill mode allows the
heat pump to monitor the temperature of the water 24
hours a day by turning the spa pump on and sampling
the water temperature.
A Maintain Temp Relay is required (provided) and
the feature must be enabled.
When the water temperature rises above the
programmed temperature set point, the control will start
the heat pump.
To operate in the spa mode with the Maintain Chill
feature, press
SPA, then press MENU, press the Down
button until
MAINTAIN SPA CHILL is displayed,
press the MENU button. The associated left green LED
indicator will light and the unit will display
SET:XXX°.
Change the temperature set point by pressing the
Up
or
Down button until the desired set point is reached.
After 5 seconds of inactivity, the new set point is stored
in memory.
5.4 User Setup Options
The User Setup options allow the user to select
specific Languages, Temperature Scale, Spa Timer, and
Display Light options.
5.4.1 Language Setup
1. Make sure the control is in the OFF mode.
2. To enter the User Setup mode, press and hold the
MENU button for 5 seconds.
NOTE The display will revert back to OFF after one
minute since the last key press.
3. To select a language, use the Up or Down button
to display SELECT USER SETUP LANGUAGE.
Press the MENU button. The SELECT
LANGUAGE ENGLISH
(default language)
appears, use the Up or Down button to scroll
through the language options. When you reach the
desired language, press the MENU button to select
the language. Press POOL or SPA to exit the
User Setup mode.
5.4.2 Temperature Scale Setup
1. Make sure the control is in the OFF mode.
2. To enter the User Setup mode, press and hold the
MENU button for 5 seconds.
3. To select temperature scale, use the
Up or Down
button to scroll through to display
SELECT
USER SETUP TEMPERATURE SCALE
. Press
the MENU button. The SELECT TEMP SCALE
°F
(default temperature scale) appears, use the
Up or Down button to scroll through the scale
options. When you reach the desired temperature
scale, press the MENU button to select. Press
POOL or SPA to exit the User Setup mode.
5.4.3 Spa Timer Setup
1. Make sure the control is in the OFF mode.
2. To enter the User Setup mode, press and hold the
MENU button for 5 seconds.
3. To select spa timer, use the
Up or Down button to
scroll through to display SELECT USER SETUP
SPA TIMER
. Press the MENU button. The
SELECT SPA TIMER CONTINUOUS (default
spa timer setting) is displayed. To turn the spa
on or off indefi nitely, press the MENU button to
select.
To select the length of time for the spa to run,
use the
Up or Down button to scroll to display
SELECT SPA TIMER TIME SELECTION. Press
the MENU button to select. The display SELECT
SPA TIME 01:00 HRS
(default time setting) is
displayed. Use the Up or Down button to select
the length of time for the spa to run (between
00:15 to 23:00 hours incremented by 00:15
minutes). Press the MENU button to select how
long the spa will run. Press POOL or SPA to exit
the User Setup mode.
5.4.4 Display Light Setup
1. Make sure the control is in the OFF mode.
2. To enter the User Setup mode, press and hold the
MENU button for 5 seconds.
3. To select display light setup, use the
Up or Down
button to scroll through to display SELECT
USER SETUP DISPLAY LIGHT
. Press the
MENU button. The SELECT DISPLAY LIGHT
2 MIN TIMEOUT
(default display light setting) is
displayed. This option allows the display light to
turn off after 2 minutes. Press the MENU button
To Next Page
