Page 28
Jandy
Heat Pump Models EE-Ti Installation and Maintenance Manual
1 Top Enclosure, Jacket 1500 R3009700
1 Top Enclosure, Jacket 2000, 2500, 3000 R3009100
2 Service Access Panel All R3000500
3 Control Cover - Smoked All R3000601
4 Fan Motor, 1/6 HP, 230 VAC 1500 R3000703
4 Fan Motor, 1/2 HP, 230 VAC 2000, 2500, 3000 R3000701
5 Contactor, 1-Phase All R3000801
5 Contactor, 3-Phase 2000, 2500, 3000 R3000802
6 Transformer, 240V 24VA All R3000901
7 Adjustable Water Pressure Switch All R3001000
8 Capacitor, Fan Motor, 3/370 MFD 1500 R3001101
8 Capacitor, Fan Motor, 7.5/370 MFD 2000, 2500, 3000 R3001100
9 Capacitor, Compressor, 60/370
(1 PH Only)
1500 R3001204
9 Capacitor, Compressor, 80/370
(1PH Only)
2000, 2500, 3000 R3001203
10 Controller Assembly, Universal All R3008800
11 Refrigerant HP Switch, 585-445 psig All R0509900
12 Refrigerant LP Switch, 58-127 psig All R0510001
12 Refrigerant LP Switch, 35-74 psig 2500R,3000R R0510002
13 Wire Harness Kit (Not Shown) All R3009000
14 Fan Blade Set 1500 R3001701
14 Fan Blade Set 2000, 2500, 3000 R3001700
15 Fan Guard 1500 R3001801
15 Fan Guard 2000, 2500, 3000 R3001800
16 Plumbing Tree Assy 1500 R0561601
16 Plumbing Tree Assy 2000, 2500, 3000 R0561602
17 Universal Union, Buttress Set All R0472700
18 Evaporator Coil/Guard 1500 R0510201
18 Evaporator Coil/Guard 2000 R0510202
18 Evaporator Coil/Guard 2500 R0510203
18 Evaporator Coil/Guard 3000 R0510204
20 Heat Exchanger Replacement Kit,
1X8
1500 R0561405
20 Heat Exchanger Replacement Kit,
2X6
2000 R0561406
20 Heat Exchanger Replacement Kit,
2X7
2500 R0561407
20 Heat Exchanger Replacement Kit,
2X8
3000 R0561408
21 Compressor (40K), 1-Phase 1500 R0510300
21 Compressor (61K), 1-Phase 2000 R0510400
21 Compressor (68K), 1-Phase 2500 R0510500
21 Compressor (83K), 1-Phase 3000 R0510600
21 Compressor (61K), 3-Phase 2000 R0510900
21 Compressor (68K), 3-Phase 2500 R0510700
21 Compressor (83K), 3-Phase 3000 R0510800
22* Thermal Expansion Valve, 4 Ton 1500 R0509501
22* Thermal Expansion Valve, 7 Ton 2000 R0509502
22* Thermal Expansion Valve, 7 Ton 2500 R0509503
22* Thermal Expansion Valve, 8 Ton 3000 R0509504
23 9 Inch Receiver All R0522500
24 Water Temperature Sensor All R3002900
25* 3-Phase Monitor (3-Phase Models
Only)
2000, 2500, 3000 R3003000
26 Air Temperature Sensor All R3003100
27* Reversing Valve (Optional) 2500R, 3000R R3003801
28* Anchor Bracket Set All R3003203
9.1 Ordering Information
To order or purchase parts for the EE-Ti models of heat pumps, contact your nearest Jandy dealer or distributor.
See the Jandy web site at www.jandy.com for the nearest service center. If they cannot supply you with what you
need, contact Zodiac customer support department, telephone (800) 822-7933.
Section 9. Replacement Parts
9.2 Jandy EE-Ti Heat Pumps Parts List
29* Heat Pump Drain Kit All R3004100
30 Junction Box Cover All R3004600
31 Power Interface PCB All R3009200
32 Fan Relay All R3009300
33 Filter Drier, 164s 1500 R0490904
33 Filter Drier, 165s 2000, 2500, 3000 R0490905
33 Filter Drier, 165s Bi-Flow 2500R, 3000R R0490906
34* Bypass Valve Assy All R3001900
Optional Components
35* Plast-aid Repair Kit All R0490800
* Not Shown
Key
No. Description Model No.
Order
Part No.
Key
No. Description Model No.
Order
Part No.
Trademarks used herein are the property of their respective owners.
