Jandy
Heat Pump Models EE-Ti Installation and Maintenance Manual
Figures and Tables
Figure 1. Jandy EE-Ti Heat Pumps Dimensions .......7
Figure 2. Anchor Clamp Positions .............................9
Figure 3. Anchor Clamp Installation ..........................9
Figure 4. Standard Plumbing Layout ....................... 11
Figure 5. Plumbing For Heating System
Combinations ........................................... 11
Figure 6. Two (2) Heat Pump Plumbing Layout ......12
Figure 7. Four (4) Heat Pump Plumbing Layout .....12
Figure 8. EE-Ti Single-Phase Electrical Supply
Wiring Diagram ........................................13
Figure 9. EE-Ti 3-Phase Electrical Supply Wiring
Diagram ...................................................14
Figure 10. Example of “MAINTAIN TEMP” Wiring to
the Time Clock .........................................15
Figure 11. EE-Ti Heat Pump Front View ...................15
Figure 12a. Remote Pool-Off-Spa Connection
(3-Wire Connection) .................................16
Figure 12b. AquaLink RS or Remote TSTAT
Connection (2-Wire Connection) ..............16
Figure 13. AquaLink RS to EE-Ti Heat Pump ...........17
Figure 14. EE-Ti Heat Pump Connection to Power
Center ......................................................18
Figure 15. Main Control Panel ..................................20
Figure 16. Winterizing the EE-Ti Heat Pump ............23
Figure 17. Heat Pump Operation Overview ..............25
Figure 18. Jandy EE-Ti Heat Pumps Exploded
View (EE2500 Shown) .............................29
Table 1. EE-Ti Heat Pump Technical
Specifications .............................................6
Table 2. Heat Pump Clearances ..............................7
Table 3. Optimal Water Chemistry Ranges ............23
Table 4. Heat Pump Troubleshouting Guide ..........26
Table 5. Heat Pump Diagnostics ...........................27
