Heat Pump Models EE-Ti Installation and Maintenance Manual
Table 1. EE-Ti Heat Pump Technical Specifi cations
MODEL EE1500T EE2000T EE2000T--263 EE2500T EE2500T-R EE2500T--263 EE2500T-R263 EE3000T EE3000T-R EE3000T--263 EE3000T-R263
VOLTAGE
230/60/1 230/60/1 230/60/3 230/60/1 230/60/3 230/60/1 230/60/3
OUTPUT*
80,000 BTUs 112,000 BTUs 120,000 BTUs 140,000 BTUs
INPUT*
3.3 kW 5.1 kW 5.6 kW 6.7 kW
COP*
7.2 6.4 6.3 6.1
OUTPUT, STANDARD RATING CONDITIONS**
67,000 BTUs 102,000 BTUs 111,000 BTUs 132,000 BTUs
COP, STANDARD RATING CONDITIONS**
6.0 5.75 5.8 5.8
OUTPUT, LOW AMBIENT**
50,000 BTUs 72,000 BTUs 76,000 BTUs 90,000 BTUs
COP, LOW AMBIENT**
4.1 4.1 4.0 4.0
RLA (RUNNING LOAD AMPS)
21A 26.9A 19.2A 26.9A 23A 26.9A 26.9
LRA (LOCKED ROTOR AMPS)
115A 145A 170A 145A 160A 145A 190A
MINIMUM CIRCUIT AMPACITY
28A 37A 27A 37A 32A 37A 36A
MAX OVER CURRENT PROTECTION***
45A 60A 45A 60A 50A 60A
HEAT EXCHANGER
Titanium
COMPRESSOR
40K Scroll 61K Scroll 68K Scroll 83K Scroll
CABINET
ABS
REFRIGERANT
64 Oz, R410A 78 Oz, R410A 90 Oz, R410A 100 Oz, R410A 90 Oz, R410A 100 Oz, R410A 114 Oz, R410A 124 Oz, R410A 114 Oz, R410A 124 Oz, R410A
REFRIGERANT HIGH PRESSURE ALARM
585 PSI (reset to 445 PSI)
REFRIGERANT LOW PRESSURE ALARM -
HEATING UNITS
58 PSI (reset to 127 PSI)
REFRIGERANT LOW PRESSURE ALARM -
REVERSE UNITS
35 PSI (reset to 74 PSI)
LOW WATER FLOW ALARM
30 GPM
MAXIMUM HEIGHT BELOW WATER LEVEL
5 feet below pool level
MINIMUM HEIGHT ABOVE WATER LEVEL
11 feet above pool level
OPTIMAL WATER FLOW
60 GPM
MINIMUM WATER FLOW
30 GPM
MAXIMUM WATER FLOW
125 GPM
AIR FLOW
2060 CFM 4120 CFM
WATER TEMPERATURE DIFFERENTIAL
(DELTA T)
Adjustable between 1°F to 5°F
UNION SIZE
2”
WEIGHT
225 LBS 325 LBS
SOUND PRESSURE PER ISO 3471
58.9 dBa
OUTPUT - Chiller****
NA 71,000 BTUs 54,000 BTUs
INPUT - Chiller****
NA 6.9 kW 7.2 kW
COP - Chiller****
NA 3.01 2.22
OUTPUT - Chiller*****
NA 87,000 BTUs 60,000 BTUs
INPUT - Chiller*****
NA 7.4 kW 7.3 kW
COP - Chiller*****
NA 3.46 2.4
* Test Conditions: 80˚ F Air, 80% RH, 80˚ F Water, Outside the scope of AHRI Standard 1160 (I-P)
** Rated in accordance with AHRI Standard 1160 (I-P)
*** Max Over Current Protection refers to the maximum breaker size allowed. If this value is not a standard breaker size, use the next smallest standard size breaker.
The breaker size must not be smaller than the Minimum Circuit Ampacity value.
**** Test Conditions: Chiller mode, 96° F Air, 50% RH, 80° F Water, Ouside the scope of AHRI Standard 1160 (I-P)
***** Test Conditions: Chiller mode, 96° F Air, 50% RH, 95° F Water, Ouside the scope of AHRI Standard 1160 (I-P)
