Model LJ Pool and Spa Heater
Page 45
JACKET COMPONENTS
77 Door with Latch 125-400 R0343601-05
78 Jacket Assembly, Less Top Assembly 125-400 R0343501-05
79 Gap Closure, Inlet/Outlet All R0344300
80 Gap Closure, Return All R0344400
81 Button Plug, 1-3/4" All F0035300
82 Button Plug, 7/8" All F0032300
83 Button Plug, 2" (With hole for gas line) All F0056600
Key Model Order
No Description No Part No.
NOTES
OPTIONAL COMPONENTS
84* Noncombustible Base 125-400 10521701-05
85 Pressure Relief Valve 3/4" NPT, 75 PSI All R0040400
86* Touch Up Spray Paint, Pewter All X0022700
87* Touch Up Spray Paint, Black All X0022900
88* Remote Control Wire Harness All R0398400
Notes:
1. Gaskets and hardware are included in all kits that require the removal of a
gasket as part of the procedure to replace a part.
* Item not shown on exploded views.
Key Model Order
No Description No Part No.
