Page 24
ENGLISH
Jandy
®
Variable-Speed Pumps
|
Installation & Operation Manual
8.2 Performance Curves
100
3450 RPM
3000 RPM 115 VAC
2750 RPM
2400 RPM
1730 RPM
1200 RPM
600 RPM
90
80
70
60
50
40
30
20
10
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 1600
0
VSPHP270DV2A(S) Performance Curves
Total Dynamic Head (Feet of Water)
Flow Rate, Gallons Per Minute (GPM)
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160
)retaW fo teeF( daeH cimanyD latoT
Flow Rate, Gallons Per Minute (GPM)
VSFHP270DV2A(S) Performance Curves
600 RPM
1200 RPM
1730 RPM
2400 RPM
2750 RPM
3000 RPM
3450 RPM
115 VAC
To Next Page
