33
UMG 508
Illu. Connection example; UMG508 and PC
need a fixed IP address.
Illu. Connection example; UMG508 and PC are
automatically allocated the IP address from a
DHCP server.
DHCP
Server
Switch
PC UMG508
Patch cable
PC
UMG508
Patch cable
Switch
Illu. Connection example; direct connection
between the UMG508 and PC using a twisted
patch cable (art. no. 08.01.505)
PC
UMG508
Patch cable
(twisted)
