UMG 508
Configuration
The supply voltage must be connected for con-
figuration of the UMG508.
Apply supply voltage
• The level of supply voltage for the UMG508
can be taken from the label.
• After applying the supply voltage, a startup
screen appears on the display. Approximate-
ly ten seconds later, the UMG508 changes to
the first „Home“ measurement value display.
• If a display does not appear, check whether
the applied supply voltage is within the nomi-
nal voltage range.
Warning!
Supply voltages that do not corres-
pond with the label details can lead to
incorrect functions and damage to the
device.
c
Illu. Example of "Home“ measurement value.
