janitza UMG 508 - Description; Intended Use

8
UMG 508
Description
Intended Use
The UMG508 is intended for measurements in
the building installation, on distributors, power
switches and bus bars.
Measurement voltages and measurement cur-
rents must come from the same network.
The UMG508 is suitable for installation in switch
boards with a fixed, weather-protected extrada-
ta.
The UMG508 can be used in 2, 3 and 4 supply
networks and in TN and TT networks.
The current measurement inputs of the UMG508
are connected using external ../1A or ../5A cur-
rent transformers.
The measurement in medium and high-voltage
networks generally takes place using current
and voltage transformers.
The UMG508 can be used in residential and in-
dustrial areas.
Measurement results can be displayed, saved
and read-out using serial interfaces for further
processing.
