35
UMG 508
Illu. Connection of two relays to digital outputs
4 and 5.
16
K1 K2
24V
AC
External
auxiliary power
UMG508
Digital outputs 1-5
Digital Outputs 1-5
12
Digital
Output 5
13
Digital
Output 4
14
Digital
Output 3
15
Digital
Output 2
Digital
Output 1
~~
11
