Table 2 - Modbus address list
(frequently used measured values)
19000 808 float RD V Voltage L1-N
19002 810 float RD V Voltage L2-N
19004 812 float RD V Voltage L3-N
19006 814 float RD V Voltage L1-L2
19008 816 float RD V Voltage L2-L3
19010 818 float RD V Voltage L3-L1
19012 860 float RD A Current, L1
19014 862 float RD A Current, L2
19016 864 float RD A Current, L3
19018 866 float RD A Vector sum; IN=I1+I2+I3
19020 868 float RD W Real power L1
19022 870 float RD W Real power L2
19024 872 float RD W Real power L3
19026 874 float RD W Sum; Psum3=P1+P2+P3
19028 884 float RD VA Apparent power S L1
19030 886 float RD VA Apparent power S L2
Modbus Address
Address Above display Format RD/WR Unit Note
C
A complete overview of the parameters and
measured values as well as explanations
regarding the selected measured values
is filed in the document “Modbus Address
List” on the CD or Internet.
C
The addresses contained in the descripti-
on can be adjusted directly on the device
in the range from 0 to 800.
The address range 800-999 is available for
programming comparators on the device.
The addresses above 1000 can only be
processed via modbus!
