janitza UMG 96RM-CBM User Manual

121
UMG 96RM-P/-CBM
Overview of measured value displays
Measured values
L1-N voltage
L2-N voltage
L3-N voltage
A01
Measured values
L1-L2 voltage
L2-L3 voltage
L3-L1 voltage
A02
Measured values
L1 current
L2 current
L3 current
A03
Measured value
Sum
Current in the N line
A04
Mean values
L1-N voltage
L2-N voltage
L3-N voltage
B01
Mean values
L1-L2 voltage
L2-L3 voltage
L3-L1 voltage
B02
Mean values
L1 current
L2 current
L3 current
B03
Mean value
Sum
Current in the N line
B04
Maximum values
L1-N voltage
L2-N voltage
L3-N voltage
C01
Maximum values
L1-L2 voltage
L2-L3 voltage
L3-L1 voltage
C02
Maximum values
L1 current
L2 current
L3 current
C03
Maximum value
Measured value sum
Current in the N line
C04
Minimum values
L1-N voltage
L2-N voltage
L3-N voltage
D01
Minimum values
L1-L2 voltage
L2-L3 voltage
L3-L1 voltage
D02
Max. values (mean value)
L1 current
L2 current
L3 current
D03
Maximum values
Sum mean value
Current in the N line
D04
Measured values
L1 active power
L2 active power
L3 active power
A05
Measured value
Sum
Active power
A06
Mean value
L1 active power
L2 active power
L3 active power
B05
Mean value
Sum
Active power
B06
Maximum values
L1 active power
L2 active power
L3 active power
C05
Maximum value
Sum
Active power
C06
Maximum value
Sum
Active power mean
value
D06
Measured values
L1 apparent power
L2 apparent power
L3 apparent power
A07
Mean values
L1 apparent power
L2 apparent power
L3 apparent power
B07
Maximum values
L1 apparent power
L2 apparent power
L3 apparent power
C07
