Configuration
Applying the supply voltage
To configure the UMG 96RM-P/-CBM, the supply
voltage must be connected.
The level of supply voltage for the UMG 96RM-P/-CBM
can be found on the nameplate.
If no display appears, check the operating voltage
to determine whether it is within the rated voltage range.
Current and voltage transformers
A current transformer is set to 5/5 A in the factory.
The pre-programmed voltage transformer ratio only
needs to be changed if voltage transformers are
connected.
When connecting voltage transformers, the measure-
ment voltage on the UMG 96RM-P/-CBM nameplate
must be observed!
c
Attention!
Supply voltages that do not correspond
to the nameplate information can lead
to device malfunction or destruction.
C
The adjustable value 0 for the primary
current transformer does not produce
any useful energy values and must not
be used.
m
Devices, which are programmed to au-
tomatic frequency detection, need ap-
proximately 20 seconds to detect grid
frequency. During this period, the mea-
sured values do not keep the confirmed
measuring accuracy.
C
Prior to commissioning potential produc-
tion dependant contents of the energy
counter, min/max values and records
have to be deleted.
