UMG 96RM-P/-CBM
Technical data for the expansions
General
Net weight Approx. 185g
Device dimensions Approx. w = 96mm, h = 96mm, d = 78mm
Service life of background lighting 40000h (50% of initial brightness)
Battery 3V, TYP CR2032 (according to UL1642)
Outputs
4 digital outputs, semiconductor relays, not short-circuit proof (there are a further two digital outputs available in the basic device).
Switching voltage Max. 33V AC, 60V DC
Switching current Max. 50mAeff AC/DC
Pulse output (energy pulse) Max. 50Hz
Inputs
4 digital inputs
Maximum counter frequency 20Hz
Input signal present 18V .. 28V DC (typical 4mA)
Input signal not present 0 .. 5V DC, current smaller than 0.5A
