Janome 5812 - Inserting the bobbin

www.toews.com
10
x Guide the thread into notch w on the front side of the
bobbin holder. Draw the thread to the left, sliding it
between the tension spring blades.
c Continue to draw the thread lightly until the thread slips
into notch e. Pull out about 6˝ (15.0 cm) of thread.
v Attach the hook cover plate. Check the threading by
referring to the diagram r shown on the hook cover plate.
Inserting the bobbin
q End of thread
w Notch
e Notch
r Threading diagram
z Place a bobbin in the bobbin holder with the thread
running off counterclockwise.
10
1/8
3/8
5/8
q
w
e
r
z
x
c
v
Janome 5812 Instruction Manual
