Janome MC 11000 Service Manual

(A)
(B)
Replacing Switching Power Supply
To remove:
1. Remove the top cover, belt cover, base, and rear
cover.
2. Remove the screws (A) and (B), and remove the
switching power supply (1).
3. Disconnect harness (2) from the switching power
supply.
To attach:
4. Follow the above procedure in reverse.
(1)
(2)
15
www.promelectroavtomat.ru

Janome MC 11000 Specifications

General

USB Connectivity	Yes
Screen Type	LCD Touch Screen
Stitch Width	7mm
Stitch Length	5mm
Needle Threader	Automatic
Buttonhole Styles	10
Automatic Thread Cutter	Yes
Built-in Memory	Yes
Type	Sewing and Embroidery
Lighting	5 LED Lights
