7
When stitches D1, D2, 8, 9 Mode 1, D01, D02, 08, 09 Mode 2 and 01, 02 Mode 3
are selected, the machine will immediately sew locking stitches when the Auto-
lock button is pressed, then automatically stop. When sewing any other stitches,
the machine will sew locking stitches at the end of the current pattern and
automatically stop.
3
1
2
4
5
Press this button to start or stop the machine. The machine starts running slowly
for the first few stitches, it then runs at the speed set by the speed control slider.
The button turned on to red while the machine running.
The button turned on to green while the machine stopping.
NOTES:
• Start/stop button cannot be used when the foot control is connected to the
machine.
• If you start the machine with the presser foot up (normal up position or extra
lifted position), the LCD screen will advise you to lower tht the machine.
(See page 11. for the presser lifter position)
2 Reverse stitch button
When stitches D1, D2, 8, 9 Mode 1, D01, D02, 08, 09 Mode 2 and 01, 02 Mode 3
are selected, the machine will sew in reverse while the reverse stitch button is
pressed.
If you press the reverse stitch button when sewing any other stitches, the machine
will immediately sew locking stitches and automatically stop.
3 Auto-lock button
4 Up/down needle position button
Press this button to bring the needle up or down. The machine will stop with the
needle up or down depending on the needle position determined by this button.
The needle position LED will turn on when the down position is selected.
5 Needle up/down stop position LED
NOTE:
The needle will always stop in the up position after sewing buttonholes,
bartacks, eyelets and darning.
If you press the up/down needle position button when the presser foot is at the
extra lifted position, the LCD screen will advise you to lower the foot.
1 Start/stop button
Function Buttons
