64
Multi -function terminal
Status and explanation
Multi
speed
1
2 3
0 0 0 0
Primary frequency, Primary
frequency is determined by P100
or potentiometer
1 0 0 0
Multi -speed 1 (P503)
0 1 0 0
Multi -speed 2 (P504)
0 0 1 0
Multi -speed 3(P505)
0 0 0 1
Multi -speed 4 (P506)
1 1 0 0
Multi -speed 5 (P507)
1 0 1 0
Multi - speed 6 (P508)
1 0 0 1
Multispeed 7(P509)
0 1 1 0
Multi -speed 8 (P510)
0 1 0 1
Multi -speed 9 (P511)
0 0 1 1
Multi -speed 10 (P512)
1 1 1 0
Multi -speed 11 (P513)
1 1 0 1
Multi -speed 12 (P514)
1 0 1 1 Multi -speed 13 (P515)
0 1 1 1 Multi -speed 14 (P516)
1 1 1 1 Multi -speed 15 (P517)
Multi
speed
Multi
speed
Multi
speed
4
6
Chapter 6 Description of parameter setting
FC100 Series User Manaul
