With the Butane Heater assembly 892/00350, seal the
connection using the following procedure.
a Remove the cap A from the end of the disposable gas
cartridge B.
b Before assembling the gas cartridge to the reflector
element C, turn the red ring D to the left, (in the
direction of the minus sign marked on the ring).
c Position the tube hanging down from inside the reflector
assembly into the hole at the top of the gas cartridge.
Then press the gas cartridge up into the reflector
assembly as far as possible until the two elements are
clasped firmly together. A click will be heard.
d Turn the small ring E so that the air holes at F are
completely closed.
