e Turn the red ring D to the right (in the direction of the
plus sign) in order to turn on the gas.
IMPORTANT: Before turning the heater on, make sure that
the cartridge is not hotter than the reflector element. This
may occur if the cartridge is held in the hand for a long time.
The temperature difference between the cartridge and the
reflector element may cause long yellow flames to appear on
ignition.
f Hold the heater vertically and, using a match or
cigarette lighter, light the gas as shown.
Note: The fact that the sound of liquid cannot be heard when
the cartridge is shaken does not mean it is empty. No sound
will be heard even when the cartridge is full.
Hold the heater vertically for 1 to 2 minutes until the
catalytic reaction occurs. This is indicated when the
blue flame fades and the ceramic element glows red.
Then turn the small ring E until the air holes at F are
completely open. The tool is ready for use.
The heater can be used in two modes:
g Side wings G down, reflector head completely open. In
this mode the infra-red heat waves are dominant
(recommended for the light coloured plastic splices).
Side wings G up (see fig at step h), reflector head
opening reduced. In this mode the heating is done only
by the hot gas (use for dark coloured plastic splices).
h To switch off the heater, turn the red ring D to the left (in
the direction of the minus sign).
Wiring Harness - Repair Procedure (cont'd)
23 - 3
Section C Electrics Section C
23 - 3
Service Procedures
9803/7130 Issue 1
S189490/5
S189490/6
S189490/7
S189490/8
DD
FF
EE
GG
GG
DD
To Next Page
