DT-300™ Series Download Tool Operator Integration Guide
10 ERROR CODES
This portion provides the Error Codes displayed on the LCD Display Screen when an error occurs.
B
OOTLOADER
E
RROR
C
ODES
Table 19 lists the Bootloader Error Codes.
M
AIN
A
PPLICATION
E
RROR
C
ODES
The following two (2) MainApplication Error Code types exist:
•
Exxx: – Error Code identifying the Error condition.
•
Dxxx: – Detailed Error Code for identifying the Error Condition of the error source causing the Error
Code. The Detailed Error Code “
Dxxx” description is same as the Error Code “Exxx”.
Table 20 lists the MainApplication Error Codes.
Table 19 Bootloader Error Codes
No. Error Code Error Message Description Remark
1 E01
Abnormal Parameter For Debug
2 E50 System Error. There is no valid Main Application
3 E51 Battery Low! Battery EMPTY
4 E52 Update Error. Firmware File Version Error Same Version or old Version
5 E53 Update Error. Firmware File Open Error
6 E54 Update Error. Firmware File Access Error
7 E55 Update Error. Firmware File Format Error
8 E56 Update Error. Firmware File Write Error
9 E57 EEPROM Error. EEPROM Data File Open Error
10 E58 EEPROM Error. EEPROM Data File Access Error
11 E59 EEPROM Error. EEPROM Data File Format Error
12 E60 EEPROM Error. EEPROM Write Error
13 E61 SD Card Error. Card Information File Authentication Error
14 E62 SD Card Error. SD Card (MMC Driver) Initialize Error
15 E63 SD Card Error. SD Card Power Control Error
16 E64 SD Card Error. SD Card non-detection Error
17 E65 SD Card Error. SD Card removal-detection Error
18 E66 SD Card Error. SD Card (MMC Driver) Finalize Error
19 E67 SD Card Error. File Relative Initialize Error
20 E68 SD Card Error. File Relative Finalize Error
21 E69 System Error. Task Control Error
22 E70 System Error. Mail Box Control Error
Table 20 MainApplication Error Codes
No. Error Code Error Message Description Remark
1 E001 Battery Low!
Battery EMPTY
2 E002 SD Card Error. SD Card Error
3 E003 Unit Type Error. Product ID Error
4 E010 USB Error. USB Host Driver Initialize Error
5 E011 USB Error. Open Error
6 E012 USB Error. Control Transfer Error
7 E013 USB Error. Information Receive Error
8 E014 USB Error. Transfer Error
9 E015 USB Error. Close Error
10 E016 USB Error. USB Host Drive Finalize Error
11 E017 USB Error. USB Connection Time Out
12 E018 USB Error. Cancel Error
13 E019 USB Error. Transfer Time Out
14 E030 SD Card Error. File System Initialize Error
NOTE: The Detailed Error Code “Dxxx” description is actually the same as the Error Code “Exxx” but
contains more information concerning the error.
