P/N 960-000167R_Rev. 1 {EDP #214645} © 2013, Japan CashMachine Co., Limited
DT-300™ Series
Download Tool
Operator Integration Guide
Revision 1
Description
This section provides a general overview of the
DT-300™ “BlueWaveDX” Downl
oad Tool Device
pictured in Figure 1. This first section is designed
to help the user navigate through this guide with
eas
e and provides the following information:
• DT-300™ Device
• Component Names
• Primary Features
• Precautions
• Specifications
• Installation
• Connector Pin Assignments
• Functions
• Unit Dimensions
• Compatibility
• Technical Contact Information.
In order to make operation of this device easier and
make
navigation within this manual simpler, the
following illustrations were used within the text:
• Safety Instructions
, which need to be
observed in order to protect the operators and
equipment, have been written in bold text and
have been given the pictographs:
• S
pecial Notes, which affect the use of the DT-
300™ Device, have been written in italic text
and have been given the pictograph:
• S
teps, requiring the operator to perform
specific actions are given sequential numbers
(1., 2., 3., etc.).
DT-300 Device
Figure 1 DT-300 BlueWaveDX Device
