IN CASE OF EMERGENCY 333
Cavity Blade Fuse Cartridge Fuse Description
F06 – – Not Used
F07 15 Amp Blue –
Powertrain Control Mod (PCM) (Diesel) / Surge Solenoid Purge Valve (Gas) – If
Equipped
F08 25 Amp Clear – Fuel Injectors (Gas), ECM (Gas), PCM/Fuel Injectors (Diesel)
F09
15 Amp Blue (Gas)
10 Amp Red (Diesel)
–
Coolant Pump (Gas) – If Equipped
UREA Coolant Pump/PCM (Diesel) – If Equipped
F10 20 Amp Yellow – Power Transfer Unit (PTU) – If Equipped
F11 – – Not Used
F12 10 Amp Red – Supply And Purging Pump (Diesel)
F13 10 Amp Red –
Voltage Stability Mod (VSM)/Powertrain Control Mod (PCM)/Engine Control
Module (ECM)
F14 10 Amp Red –
Drivetrain Control Module (DTCM)/Power Take-Off Unit (PTU)/Electric Park Brake
(EPB)/RDM/Brake System Module (BSM) – If Equipped/Brake Pedal Switch/Back
Up Lamp Switch (Diesel)
F15 – – Not Used
F16 20 Amp Yellow – Ign Coils / Additional Diesel Content
F17 30 Amp Pink – Brake Vacuum Pump (GAS GMET4/V6 Engines Only)
F18 – – Not Used
F19 – 40 Amp Green Starter Solenoid
F20 10 Amp Red – A/C Compressor Clutch
F21 – – Not Used
