F22 5 Amp Tan – Radiator Fan (PWM) Enable
F23 50 Amp Red – Voltage Stability Module (VSM) #2
F24 20 Amp Yellow – Rear Wiper
F25B 20 Amp Yellow – FT/RR Washer
F26 – 30 Amp Pink Fuel Heater (Diesel)
F27 – – Not Used
F28 15 Amp Blue – Transmission Control Module (TCM/Shifter)
F29 – – Not Used
F30 10 Amp Red –
Engine Control Module (ECM)/(EPS)/Fuel Pump Relay Feed/(PCM)/Gas
Particulate Filter (GPF)
F31 – – Not Used
F32 – – Not Used
F33 – – Not Used
F34 – – Not Used
F35 – – Not Used
F36 – – Not Used
F37 – – Not Used
F38 – 60 Amp Yellow Glow Plugs (Diesel)
F39 – 40 Amp Green HVAC Blower Motor
F40 – 20 Amp Blue Trailer Tow Park Light – If Equipped
F41 – 50 Amp Red Voltage Stability Module (VSM) #1
Cavity Blade Fuse Cartridge Fuse Description
