Setting up the ECU
These are the first steps you need to complete before operating the v4.0 ECU. Make
sure your batteries are charged, the ECU is off and the GSU is connected.
Do not perform the calibration of the temperature probe if this is a new engine.
Temperature probe calibration is for ECU updates only.
Calibrate the temperature probe.
To compensate the differences from engine to engine there is an offset number that is
used to correct the temperature displayed. This offset is derived by sampling the actual
temperature read from the engine compared to the ambient room temperature.
Your engine should be at approximately room temperature, 21 °C.
Press and hold the Select Menu key on the GSU, then switch on the power.
* Remark:
Instead of pressing the Select Menu key on the GSU, the little key on the LED
board can be use instead.
The three LED´s first show the following blinking sequence:
LED Blink Sequence
Standby/Man.
Yellow ~ { { ~ { {
Pump running
Red { Ö ~ Ö { Ö { Ö ~ Ö {
OK
Green { { ~ { { ~ ....
The Display of the GSU will also show the message:
Release key to:
- learn RC -
Keep the Select Menu key pressed during this blinking sequence. It takes up to 10
seconds!
Only release the key when the 3 LED´s are showing the following sequence:
LED Blinking sequence
Standby Yellow ~ { ~ { ~ {
Pump running Red { Ö ~ Ö { Ö ~ Ö { Ö ~ Ö
OK Green ~ { ~ { ~ { ....
The Display of the GSU will change to the message:
Release key to:
Calibrate Temp
Æ now release the key
31
