Starting Gas Diagram
4 -> 3mm tubing adapter
3mm tubing to turbine
4mm tubing
4mm tubing
Starting Gas
Shutoff Valve
On Board
Starting Gas
Tank
Petcock
(Starting Gas Vent)
Plastic Barb
(To Offboard Gas Fill)
4mm tubing
One Way Festo
(Note markings!)
Keep Line Short !
Coleman
Powermax
Starting Gas
Filter
22
