JetCat SPH5 User Manual

In addition to the default display, the following selections can be monitored on the upper
display line. Use the ◄ - / ►+ keys alone for selecting the different parameters.
Value Explanation
Default
Display
See above for description.
U-Pump /
RPM
Current pump voltage.
Current RPM.
Temp. /
RPM
Current EGT (Exhaust Gas Temperature).
Current RPM.
OffCnd
SetRpm /
Set RPM
Last Off command (reason for shut down). See table on page 43.
Commanded RPM.
State /
RPM
Current turbine state.
Current RPM.
The Min/Max Menu
The Min/Max menu is used primarily for diagnostics purposes. All of the following
variables may be reset manually by pressing the Change Value/Item key on the GSU.
Although the display will indicate that the values cannot be changed, it will reset the
Min/Max values.
Value Explanation
Upump-Max
Upump-Min
Maximum pump voltage.
Minimum pump voltage.
MaxTemp
MinTemp
Maximum EGT.
Minimum EGT.
AvgPump
AvgTemp
Average pump voltage
Average temperature
MaxRpm
MinRpm
Maximum turbine RPM.
Minimum turbine RPM.
AvgRpm
MaxRTmp
Average RPM
Average temperature at maximum RPM during the last run.
