AD-1272 Advanced Thermal Dispersion Probe Airflow Measuring System Technical Bulletin
35
BACnet Temperature Alarm Configuration
The BACnet Temperature Alarm Configuration submenu is only available when BACnet is on (see BACnet Network
Configuration). In this submenu, you can configure temperature parameters including high and low alarms,
setpoints, and alarm delay.
Table 16: BACnet Temperature Alarm Configuration Submenu Selections and Configurable Options (Part 1
of 2)
BACnet Temperature
Alarm Configuration
Submenu Selections
Configurable Options
Alarm Low On/Off Select On or Off.
Alarm High On/Off Select On or Off.
Alarm Low Setpoint Choose a value the temperature must go below for an alarm condition to exist.
Alarm High Setpoint Choose a value the temperature must surpass for an alarm condition to exist.
Figure 61: BACnet Temperature Alarm Configuration Flowchart
UP
DOWN
Alarm High On/Off
BACNet Temperature
Alarm Low On/Off
UP
DOWN
ENTER
ENTER
ESC or ENTER
ESC
ENTER
ESC or ENTER
Alarm Low
Setpoint
ENTER
ESC or ENTER
UP DOWN
Alarm High
Setpoint
ENTER
UP
DOWN
ESC or ENTER
Alarm Deadband
ENTER
ESC or ENTER
Alarm Delay
ENTER
UP
DOWN
ESC
*Default values shown
UP
DOWN
Exit this Menu
ENTER
DOWN
UP
Returns to
Operator Menu
Selected Submenu
Submenu Selections
Submenu Selection Display
F
I
G
:
f
l
o
w
c
h
a
r
t
_
b
a
c
n
e
t
_
t
e
m
p
Alarm
