Start-Up & Operation Guide | 5586996-JSG-A-0120
77
Operation
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
Clg > Setup
DAT-Spcong (Discharge Air
Temperature Setpoint Conguration)
Fixed, OA Temp Reset, Supply Fan Reset, Zone
Temp Reset, External
ClgDATUp-SP (Cooling Discharge Air
Temperature Upper Setpoint)
deg F (41–80)
ClgDATLo-SP (Cooling Discharge Air
Temperature Lower Setpoint)
deg F (40–79)
OAT-ResetSpLower (OAT Reset
Setpoint Lower)
deg F (50–99)
OAT-ResetSpUpper (OAT Reset
Setpoint Upper)
deg F (51–111)
ZT-ResetSpLower (ZT Reset Setpoint
Lower)
deg F (50–80)
ZT-ResetSpUpper (ZT Reset Setpoint
Upper)
deg F (51–81)
SF-DAT-SpHighThresh (Supply Fan
DAT Setpoint High Threshold)
% (0–100)
SF-DAT-SpLowThresh (Supply Fan DAT
Setpoint Low Threshold)
% (0–100)
C1A-En (Compressor 1A Enabled) Yes, No
C1B-En (Compressor 1B Enabled) Yes, No
C2A-En (Compressor 2A Enabled) Yes, No
C2B-En (Compressor 2B Enabled) Yes, No
Circ1ClgOATCutout (Circuit 1 OAT
Cooling Cutout)
deg F (…75)
Circ2ClgOATCutout (Circuit 2 OAT
Cooling Cutout)
deg F (…75)
MornC-En (Morning Cool Down Enabled) No, Yes
MornCRAT-Sp (Morning Cool Down/
Return Air Temperature Setpoint)
deg F (50–85)
MornCDAT-Sp (Morning Cool Down
Discharge Air Temperature Setpoint)
deg F (40–69)
Clg > Service
> Unit -
Service Menu
(For service
technicians to
get detailed
information)
StgClgCmd (Staged Cooling Command)
Clg-S (Cooling Status)
OFF-Idle, Thermostat Cooling, Unoccupied
Cooling, Occupied Cooling, OFF-OAT Lockout,
OFF-Disabled, OFF-Lockout, OFF-Low Supply
Voltage, OFF-Low Ambient, OFF-Low Ambient Pre-
Run Delay, OFF-Waiting for Changeover Delay,
OFF-Free Cooling, Comfort Ventilation
OprClg-Sp (Operating Cooling Setpoint) deg F (0–100)
OprClgDAT-SP (Operating Cooling
Discharge Air Temperature Setpoint)
deg F
OprOAT (Operational Outside Air
Temperature)
deg F
OprZT (Operational Zone Temperature) deg F
RAT (Return Air Temperature) deg F
Econ-Free (Economizer Free Cooling
Available)
No, Yes
