Johnson Controls GVB Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
78
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
Clg > Service
> Unit -
Service Menu
(For service
technicians to
get detailed
information)
DAT (Discharge Air Temperature) deg F
Y1-Tstat (Y1 - Thermostat) OFF, ON
Y2-Tstat (Y2 - Thermostat) OFF, ON
NumCondFansCir1 / Set by Factory 1–2
CF-1A (Condenser Fan 1A) OFF, ON
CF-1B (Condenser Fan 1B) OFF, ON
NumCondFansCir2 / Set by Factory 1–2
CF-2A (Condenser Fan 2A) OFF, ON
CF-2B (Condenser Fan 2B) OFF, ON
ModCondFanCir1En (Circuit 1
Modulating Condenser Fan Installed)
True, False
ModCondFan1Out (Modulating
Condenser Fan 1 Output)
% (0–100)
ModCondFanCir2En (Circuit 2
Modulating Condenser Fan Installed)
True, False
ModCondFan2Out (Modulating
Condenser Fan 2 Output)
% (0–100)
MinRtCoolStg (Minimum Runtime for a
Cooling Stage)
minutes (3–10)
RpdStrtTime (Rapid Start Time Limit) minutes (0–15)
ClgAdapTunEn (Cooling Adaptive
Tuning Enable) / No
No, Yes
Clg > Service
> Stage 1A,
Stage 1B,
Stage 2A,
Stage 2B
C1A-S (Compressor 1A Status)
OFF-Idle, ON-Minimum On Time, ON-Normal
Command, OFF-Cooling is Disabled, OFF-OAT
Cutout, OFF-Low Ambient Temperature, OFF-Low
Supply Voltage, OFF-High Pressure Lockout, OFF-
Low Pressure Lockout, OFF-Freeze Condition,
OFF-Anti-Short Cycle Delay, OFF-Cooling Stage is
Disabled
C1A (Compressor 1A Command) Off, On
C1AOnTimer (Min On Time Remaining
1A)
seconds
C1A-ASCDTmr (Anti-Short Cycle Delay
Time Remaining 1A)
seconds
C1A-RunTime hours (0–10,000)
C1A-Starts counts (0–2,000,000)
C1A-Cap (Compressor Capacity 1A) % (0–50)
ModCompOut (Modulating Compressor
Output)
% (0–100)
Clg > Sensors
EVAP-T (Evaporator Temperature) deg F
SLP-1 (Suction Line Pressure 1) psi
LLP-1 (Liquid Line Pressure 1) psi
DLP1 (Discharge Line Pressure 1) psi
SLT-1 (Suction Line Temperature 1) deg F
LLT-1 (Liquid Line Temperature 1) deg F
DLT1 (Discharge Line Temperature 1) deg F
SLP-2 (Suction Line Pressure 2) psi
