Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
Clg > Sensors
LLP-2 (Liquid Line Pressure 2) psi
DLP2 (Discharge Line Pressure 2) psi
SLT-2 (Suction Line Temperature 2) deg F
LLT-2 (Liquid Line Temperature 2) deg F
DLT2 (Discharge Line Temperature 2) deg F
Clg > Safeties
(Display unit
status; not
adjustable)
SS-S (Safety Switch Status) Normal, Alarm
COMP1-A (Compressor Safety Chain 1) Normal, Alarm
COMP1-LO (Compressor Safety Chain
Lockout 1)
Normal, Lockout
LPS1 (Low Pressure Safety 1) Normal, Alarm
LPS1-LO (Low Pressure Lockout 1) Normal, Lockout
COMP2-A (Compressor Safety Chain 2) Normal, Alarm
COMP2-LO (Compressor Safety Chain
Lockout 2)
Normal, Lockout
LPS2 (Low Pressure Safety 2) Normal, Alarm
LPS2-LO (Low Pressure Lockout 2) Normal, Lockout
COND-A (Condensate Alarm) Alarm, Normal
C1A-HP-Unload (Compressor 1A High
Pressure Unload)
Alarm, Normal
C1B-HP-Unload (Compressor 1B High
Pressure Unload)
Alarm, Normal
C2A-HP-Unload (Compressor 2A High
Pressure Unload)
Alarm, Normal
C2B-HP-Unload (Compressor 2B High
Pressure Unload)
Alarm, Normal
C1A-LP-Unload (Compressor 1A Low
Pressure Unload)
Alarm, Normal
C1B-LP-Unload (Compressor 1B Low
Pressure Unload)
Alarm, Normal
C2A-LP-Unload (Compressor 2A Low
Pressure Unload)
Alarm, Normal
C2B-LP-Unload (Compressor 2B Low
Pressure Unload)
Alarm, Normal
Clg > FDD
Altitude / 0 feet feet (-1,500 to 30,000)
RunContAlmDly (Unit Running
Continuously Alarm Delay) / 23 hours
hours (1–99)
RunContAlm (Unit Running
Continuously Alarm)
Normal, Alarm
BASTrimRespond-En (BAS Trim and
Respond Enabled) / Disable
Disable, Enable
SPNoChangeAlm (Setpoint Not
Changing Alarm)
Normal, Alarm
DownInOccAlm (Unit Down in Occupied
Alarm)
Normal, Alarm
LowCoolCapAlm (Insufcient Cooling
Capability Alarm)
Normal, Alarm
