Operation of the Control Panel System or Point Trouble Event
28 IFC-3030 Operations Manual — PN 52026:C 08/05/2005
System Troubles
A message from the “Trouble Type” column in Table 2.2 will appear in the second line on the left
of the panel display when a device trouble occurs. Use this table to help determine the cause of the
trouble.
RFX COMM LOSS Communication has been lost with an RFX
device
Check the RFX to determine the problem.
SECURITY TAMPER An RFX device has been removed from its base. Check the RFX device for tampering.
SHORT CIRCUIT The module device has a short circuit on its
supervised wiring.
Check the connections from the module to the input or
output device to which it is wired.
VERIFY OVER MAX This detector, or M302MJ or panel circuit monitor
module, which has been programmed to
participate in alarm verification, has gone into
and come out of its programmed verification limit
without going into alarm. Either something is
wrong with the detector or there is a condition
nearby (such as someone smoking) that causes
it to go into verification frequently.
Check the detector and the conditions nearby to
determine the problem.
POINT TROUBLES
TROUBLE TYPE TROUBLE DESCRIPTION ACTION
Table 2.1 Point (Device) Troubles (2 of 2)
SYSTEM TROUBLES
TROUBLE MESSAGE TYPE TROUBLE DESCRIPTION
ADV WALK TEST There is an Advanced Walk Test in progress.
ANNUN x
NO ANSWER The annunciator at address x is not responding.
ANNUN x
TROUBLE The annunciator at address x is in trouble.
AUXILIARY TROUBLE Auxiliary device connected to the IFC-3030 CPU at J5 is in trouble or cable is missing.
BASIC WALK TEST A Basic Walk Test is in progress.
CORRUPT LOGIC EQUAT The database that houses the panel’s logic equations is corrupt. It must be re-downloaded, or all
programming must be cleared and re-entered.
DRILL INITIATED Drill has been initiated locally.
DRILL RECEIVED Drill has been initiated remotely.
EPROM ERROR The application and/or boot code is corrupt. Service required.
EXTERNAL RAM ERROR The external RAM test failed. Service required.
GROUND FAULT A ground fault has occurred within the panel.
GROUND FAULT LOOP x
There is a ground fault on loop x.
INTERNAL RAM ERROR The internal RAM test failed. Service required.
LOADING.NO SERVICE A program or database download is in progress. The panel is NOT providing fire protection during
the download. Proper authorities should be notified while a download is in progress so that other
means of fire protection can be supplied.
LOOP x
- x COMM FAILURE Loops x and x are not responding. The LCM and LEM for those loops must be serviced.
MAN EVAC INITIATED Local initiation of DRILL.
MAN EVAC RECEIVED Network initiation of DRILL.
MANUAL MODE ENTERED An annunciator has been placed in manual mode.
NCM COMM LOSS Communication is lost between the JCPU-3030 and the NCM.
NETWORK FAIL PORT x Communication lost between NCM Port x and corresponding node.
NETWORK INCOMPATIBILITY An incompatible product exists on this network.
NFPA 24HR REMINDER This message occurs every day at 11 am if any troubles exist.
NVRAM BATT TROUBLE Battery backup and/or clock backup is low. Replace battery.
NO DEV. INST ON L1 No devices are installed on the system.
Table 2.2 System Troubles (1 of 2)
To Next Page
