General Zone Read Status
IFC-3030 Operations Manual — PN 52026:C 08/05/2005 47
3.8 General Zone
When a general zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display
Figure 3.8 General Zone Screen - Read Status
Display
Lines 1 through 7 - Refer to the descriptions in "Smoke Detector" on page 42.
Line 15 - the current time and date
3.9 Logic Zone
When a logic zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display
Figure 3.9 Logic Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in "Smoke Detector" on page 42.
EQUATION: The logic equation for this logic zone is displayed here
Line 15 - Current time and date.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
READ ADDRESS: Z066
AUTOMATIC INACTIVE
66TH FLOOR Z066
10:22:34A FRI SEP 24, 2004
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
READ ADDRESS: ZL0066
AUTOMATIC INACTIVE
LOGIC ZONE NUMBER 66 ZL0066
EQUATION:
AND(L1D1,L2D1)
10:22:34A FRI SEP 24, 2004
BACK
