Trouble Zone Read Status
IFC-3030 Operations Manual — PN 52026:C 08/05/2005 49
Display
Lines 1 through 6 - Refer to the descriptions in "Smoke Detector" on page 42.
Line 7 - The special zone number and function is displayed here.
3.12 Trouble Zone
When a trouble zone address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display.
Figure 3.12 Trouble Zone Screen - Read Status
Display
Lines 1 through 6 - Refer to the descriptions in "Smoke Detector" on page 42.
EQUATION: The equation for this trouble zone is displayed here.
Line 15 - Current time and date.
3.13 Annunciator
When an annunciator address is entered into the Point Select Screen and the ACCEPT soft key is
pressed, the following screen will display if the point is a monitor module.
Figure 3.13 Annunciator Screen - Read Status
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
READ ADDRESS: ZT008
AUTOMATIC INACTIVE
TROUBLE ZONE NUMBER 008 ZT008
EQUATION:
AND(T15,T16)
10:22:34A FRI SEP 24, 2004
BACK
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
READ ADDRESS: A08P09
MODE: CONTROL
ACTIVE LED: OFF
TROUBLE LED: OFF
SOURCE: L01M001 L01M002
BACK
