Viewing and Printing History Information Time and Date Range Selection for All Events
52 IFC-3030 Operations Manual — PN 52026:C 08/05/2005
PREVIOUS EVENT - Press to view previous event (In the above example, event 003 of 017).
PRINT “xxx” HISTORY - Press to print the history for the event(s) chosen. (In the above
example, all 17 events). The report will look like this:
4.2 Time and Date Range Selection for All Events
Pressing the Time/Date Interval soft key on the History Select screen displays the Time & Date
Range Select screen. This screen allows for selection of a time period that defines the range of
events to be viewed and/or printed.
Figure 4.2 Time & Date Range Select Screen
Display
See description in "Events History" on page 51 for lines 1-5.
Soft Keys
START TIME: - Use the keypad to enter a start time for event viewing in the following format:
HH:MMA/P DDD MM/DD/YY
END TIME: - Use the keypad to enter an end time for event viewing.
EVENT TYPE: - Press this soft key to scroll through the following: ALL EVENTS, ALARMS
ONLY, TROUBLES ONLY, SUPERVISORY ONLY, SECURITY ONLY, OTHER ONLY. Stop
scrolling at the desired event type.
ACCEPT: - When entries are made, press this soft key to proceed to the All Events in Interval
Screen.
All Events in Interval Screen
This screen is the same as the Event History screen, except for its title. Refer to Figure 4.1 on page
51.
******EVENT HISTORY************************************************************
TROUBLE
TM4 NO ANSWER 08:52:05P SAT AUG 14, 2004
ACK TROUBLE
TM4 NO ANSWER 08:53:35P SAT AUG 14, 2004
CLEAR TROUBLE
TM4 NO ANSWER 08:54:05P SAT AUG 14, 2004
*******************************************************************************
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A WED AUG 25, 2004
TIME & DATE RANGE SELECT
START TIME: 12:00A THU 08/19/04
END TIME: 02:00P MON 08/23/04
EVENT TYPE: ALL EVENTS ACCEPT
BACK
