44 IFC-3030 Operations Manual — PN 52026:C 08/05/2005
3.4 Monitor Module
When a module address is entered into the Point Select Screen and the ACCEPT soft key is pressed,
the following screen will display if the point is a monitor module.
Figure 3.4 Monitor Module Screen - Read Status
Display
Lines 1 through 10 - Refer to the descriptions in "Smoke Detector" on page 42.
Lines 13 and 14 - When a module is monitoring an AMPS-24 or an ACPS-2406, information will
appear in these lines in the following format.
BATTERY VOLTAGE: 27.9 VOLTS
CHARGER CURRENT: 0.0 AMPS
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
3.5 Control Module
When a module address is entered into the Point Select Screen and the ACCEPT soft key is pressed,
the following screen will display if the module is a control module.
Figure 3.5 Control Module Screen - Read Status
Display
Lines 1 through 10 - Refer to the descriptions in "Smoke Detector" on page 42 with the exception
of line 6, which is described below.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
READ ADDRESS: L03M052
AUTOMATIC INACTIVE
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 PULL STATION
Z022, Z027, Z066, , ,
, , , , ,
10:22:34A FRI SEP 24, 2004
BACK
Battery voltage
and charger
current will appear
in lines 13 and 14
if the module is
monitoring an
AMPS-24 or an
ACPS-2406. See
text below.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A FRI SEP 24, 2004
READ ADDRESS: L03M052
AUTOMATIC OFF
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 CONTROL
Z005, Z027, Z066, , ,
, , , , ,
WALK TEST: YES
SWITCH INHIBIT: YES
SILENCEABLE: YES - RESOUND FIRE
10:22:34A FRI SEP 24, 2004
BACK
